Types

An enumeration is compatible with the type that the translator chooses to represent it, but the choice is implementation defined. The translator can represent an enumeration as any integer type that promotes to int. A value you specify for an enumeration constant (such as 4 for blue above) must be an arithmetic constant expression and representable as type int. If you write:

enum Hue {red, green, blue = 4} x;
int *p = &x;         DANGEROUS PRACTICE

not all translators treat &x as type pointer to int.

Floating-Point Types

The translator predefines three floating-point types. All represent values that are signed approximations to real values, to some minimum specified precision, over some minimum specified range. The following table lists the properties of the three floating-point types:

             Minimum             Restrictions on
Designation  Range               Representation

float        [-10^+38, -10^-38]  at least 6 decimal digits
             0                   of precision
             [10^-38, 10^+38]

double       [-10^+38, -10^-38]  at least 10 decimal digits;
             0                   range and precision
             [10^-38, 10^+38]    at least that of float

long double  [-10^+38, -10^-38]  at least 10 decimal digits;
             0                   range and precision
             [10^-38, 10^+38]    at least that of double

No relationship exists between the representations of integer types and floating-point types.

Deriving Types

You can derive types from other types by declaring:

• pointers to other types
• structures containing other object types
• unions containing other object types
• arrays of other object types
• functions that return object or incomplete types

You cannot call a function that returns an incomplete type other than void. Any other incomplete return type must be complete before you call the function.

The following table summarizes the constraints on deriving types:

Derived      Function    Object         Incomplete
Type         Type        Type           Type

pointer to   any         any except      any
                         bitfield types

structure    ---         any             ---
containing

union        ---         any             ---
containing

array of     ---         any except      ---
                         bitfield types

function     ---         any except      any except
returning                bitfield types  incomplete
                         or array types  array types

Pointer Types

A pointer type describes an object whose values are the storage addresses that the program uses to designate functions or objects of a given type. You can declare a pointer type that points to any other type except a bitfield type. For example:

char *pc;                pc is a pointer to char
void *pv;                pv is a pointer to void
void (*pf)(void);        pf is a pointer to a function

Several constraints exist on the representation of pointer types:

• Every pointer type can represent a null pointer value that compares equal to an integer zero, and does not equal the address of any function or object in the program.
• The types pointer to char, pointer to signed char, pointer to unsigned char, and pointer to void share the same representation.
• Any valid object pointer can safely be converted to pointer to void and back to the original type.
• All pointer to function types share the same representation (which need not be the same as for pointer to void).
• Otherwise, different pointer types can have different representations.

No relationship exists between the representations of pointer types and integer or floating-point types.

Structure Types

A structure type describes an object whose values are composed of sequences of members that have other object types. For example:

struct {
    char ch;             struct contains a char
    long lo;             followed by a long
    } st;                st contains st.ch and st.lo

The members occupy successive locations in storage, so an object of structure type can represent the value of all its members at the same time. Every structure member list (enclosed in braces) within a given translation unit defines a different (incompatible) structure type.

Some implementations align objects of certain types on special storage boundaries. A Motorola 680X0, for example, requires that a long object be aligned on an even storage boundary. (The byte with the lowest address, used to designate the entire object, has an address that is a multiple of 2.)

A structure type can contain a hole after each member to ensure that the member following is suitably aligned. A hole can occur after the last member of the structure type to ensure that an array of that structure type has each element of the array suitably aligned. In the Motorola 68000 example above, a one-byte (or larger) hole occurs after the member ch, but a hole probably does not occur after the member lo. Holes do not participate in representing the value of a structure.

Union Types

A union type describes an object whose values are composed of alternations of members that have other object types. For example:

union {
    char ch;             union contains a char
    long lo;             followed by a long
    } un;                un contains un.ch or un.lo

All members of a union type overlap in storage, so an object of union type can represent the value of only one of its members at any given time. Every union member list (enclosed in braces) within a translation unit defines a different (incompatible) union type.

Like a structure type, a union type can have a hole after each of its members. The holes are at least big enough to ensure that a union type occupies the same number of bytes (regardless of which member is currently valid) and to ensure that an array of that union type has each element of the array suitably aligned.

Array Types

An array type describes an object whose values are composed of repetitions of elements that have some other object type. For example:

char ac[10];             contains chars ac[0], ac[1], etc.

Elements of an array type occupy successive storage locations, beginning with element number zero, so an object of array type can represent multiple element values at the same time.

The number of elements in an array type is specified by its repetition count. In the example above, the repetition count is 10. An array type does not contain additional holes because all other types pack tightly when composed into arrays. The expression you write for a repetition count must be an arithmetic constant expression whose value is greater than zero.

Function Types

A function type describes a function whose return value is either an object or an incomplete type other than an array type. A void return type indicates that the function returns no result. A function type can also describe the number and types of arguments needed in an expression that calls the function. For example:

double sinh(double x);   one double argument,
                         returns double result
void wrapup(void);       no argument or return value

A function type does not represent a value. Instead, it describes how an expression calls (passes control to) a body of executable code. When the function returns (passes control back) to the expression that calls it, it can provide a return value as the value of the function call subexpression.

Incomplete Types

An incomplete type can be a structure type whose members you have not yet specified, a union type whose members you have not yet specified, an array type whose repetition count you have not yet specified, or a void type. You complete an incomplete type by specifying the missing information. Once completed, an incomplete type becomes an object type.

You create an incomplete structure type when you declare a structure type without specifying its members. For example:

struct complex *pc;      pc points to incomplete
                         structure type complex

You complete an incomplete structure type by declaring the same structure type later in the same scope with its members specified, as in:

struct complex {
    float re, im;
    };                   complex now completed

You create an incomplete union type when you declare a union type without specifying its members. For example:

union stuff *ps;         ps points to incomplete
                         union type stuff

You complete an incomplete union type by declaring the same union type later in the same scope with its members specified, as in:

union stuff {
    int in;
    float fl;
    };                   stuff now completed

You create an incomplete array type when you declare an object that has array type without specifying its repetition count. For example:

char a[];                a has incomplete array type

You complete an incomplete array type by redeclaring the same name later in the same scope with the repetition count specified, as in:

char a[25];              a now has complete type

You write a void type as the keyword void, with an optional (but meaningless) type qualifier. You can declare but you cannot define an object of void type. You cannot complete a void type.

Type Qualifiers

You can qualify any object type or incomplete type with any combination of the two type qualifiers const and volatile. Each type qualifier designates a qualified version of some type. The qualified and unqualified versions of a type have the same representation:

• A const-qualified type indicates that access to the designated object cannot alter the value stored in the object. All other object types can have their values altered.
• A volatile-qualified type indicates that agencies unknown to the translator can access or alter the value stored in the object. The translator can assume that it has complete control of all objects that do not have volatile-qualified types.

You write a type qualifier within a declaration either as part of the type part or as part of a pointer decoration. All combinations of pointer decorations and type qualifiers are meaningful. A few examples are:

volatile int vi;         vi is a volatile int
const int *pci;          pci points to const int
int *const cpi;          cpi is a const pointer to int
const int *const cpci;   cpci is a const pointer to const int
const int *volatile      vpci is a volatile pointer
    vpci;                to const int

Moreover, all four combinations of type qualifiers are meaningful:

• You specify no type qualifiers for the ``normal'' objects in the program.
• You specify const-qualified types for objects that the program does not alter (such as tables of constant values).
• You specify volatile-qualified types for objects accessed or altered by signal handlers, by concurrently executing programs, or by special hardware (such as a memory-mapped I/O control register).
• You specify both const- and volatile-qualified types for objects that the program does not alter, but that other agencies can alter (such as a memory-mapped interval timer).

If you declare an object as having a const-qualified type (such as cpi in the example above), then no expression within the program should attempt to alter the value stored in the object. The implementation can place the object in read-only memory (ROM) or replace references to its stored value with the known value.

A pointer to const-qualified type can point to an object that does not have const-qualified type. A pointer to a type that is not const-qualified can point to an object that has const-qualified type. You should not, however, alter the value stored in the object with such a pointer.

For example:

const int ci, *pci;
int i, *pi;
pci = &i;                permissible
pi = (int *)&ci;         type cast required
i = *pci + *pi;          permissible
*pci = 3;                INVALID: *pci is const
*pi = 3;                 INVALID: ci is const

If you declare an object as having a volatile-qualified type (such as vi in the example above), then no expression within the program should access or alter the value stored in the object via an lvalue that does not have a volatile-qualified type.

A pointer to volatile-qualified type can point to an object that does not have volatile-qualified type. A pointer to a type that is not volatile-qualified can point to an object that has volatile-qualified type. You should not, however, access the object with such a pointer.

Compatible and Composite Types

In many contexts, the translator must test whether two types are compatible, which occurs when one of the following conditions is met:

• Both types are the same.
• Both are pointer types, with the same type qualifiers, that point to compatible types.
• Both are array types whose elements have compatible types. If both specify repetition counts, the repetition counts are equal.
• Both are function types whose return types are compatible. If both specify types for their parameters, both declare the same number of parameters (including ellipses) and the types of corresponding parameters are compatible. Otherwise, at least one does not specify types for its parameters. If the other specifies types for its parameters, it specifies only a fixed number of parameters and does not specify parameters of type float or of any integer types that change when promoted.
• Both are structure, union, or enumeration types that are declared in different translation units with the same member names. Structure members are declared in the same order. Structure and union members whose names match are declared with compatible types. Enumeration constants whose names match have the same values.

Some examples of compatible types are:

long                     is compatible with long
long                     is compatible with signed long
char a[]                 is compatible with char a[10]
int f(int i)             is compatible with int f()

Two types are assignment compatible if they form a valid combination of types for the assignment operator (=).

The translator combines compatible types to form a composite type. The composite type is determined in one of the following ways:

• For two types that are the same, it is the common type.
• For two pointer types, it is a similarly qualified pointer to the composite type pointed to.
• For two array types, it is an array of elements with the composite of the two element types. If one of the array types specifies a repetition count, that type provides the repetition count for the composite type. Otherwise, the composite has no repetition count.
• For two function types, it is a function type that returns a composite of the two return types. If both specify types for their parameters, each parameter type in the composite type is the composite of the two corresponding parameter types. If only one specifies types for its parameters, it determines the parameter types in the composite type. Otherwise, the composite type specifies no types for its parameters.
• For two structure, union, or enumeration types, it is the type declared in the current translation unit.

For example, the following two types are compatible:

FILE *openit(char *)     and FILE *openit()

They have the composite type:

FILE *openit(char *)

For a more complex example, the two types:

void (*apf[])(int x)     and void (*apf[20])()

are compatible and have the composite type:

void (*apf[20])(int x)
